Reduced titanium oxide (TiOx)-coated mica and glass microparticles, providing a deeper pearlescent black compared to traditional mica-and glass-based pigments.

Applications

Paint and Coatings
Printing Ink
Plastic Additives

Features

Good dispersability
Stability in water
Heat and chemical resistance

Additional Information

Global Registration
	Country	M010-1	M010-2	G020L	G014H	G070H
MITI	Japan	○	○	○	○	○
EINECS	EU	○	○	○	○	○
REACh	EU	△	△	△	△	△
TSCA	USA	LVE (10 ton/Y as Tilack D Layer)
IECSC	China	○	○	○	○	○
ECL	Korea	○	○	○	○	○
ECN	Taiwan	○	○	○	○	○
AICS	Australia	x	x	x	x	x
PICCS	Philippines	x	x	x	x	x
○：Registered、△：Pre-Registered、×：Not-Listed

Product Specification

Grade	Specification
Grade	Color	Base	Thickness	D10	D50	D90
Black Diamond M010-1	Black	Natural Mica	400-500nm	1µm	1µm	18µm
Black Diamond M010-2	Black	Natural Mica	400-500nm	5.8µm	10µm	14µm
Black Diamond G014H	Black	Glass Flake	1µm	8.5µm	14µm	26µm
Black Diamond G020L	Black	Glass Flake	1µm	10.7µm	20µm	32µm
Black Diamond G030H	Black	Glass Flake	1µm		30µm
Black Diamond G070H	Black	Glass Flake	1µm	37µm	70µm	124µm
Scales Color M020-B	Black-Blue	Natural Mica	400-500nm		20µm
Scales Color M020-G	Black-Green	Natural Mica	400-500nm		20µm
Scales Color M020-R	Black-Red	Natural Mica	400-500nm		20µm
Scales Color M020-Y	Black-Yellow	Natural Mica	400-500nm		20µm

Product Varieties

We offer eight different grades of Black Diamond®: Two grades on a Mica base (M010-1, M010-2) and six grades on a Glass base (G014H, G014L, G020L, G020H-Y, G030H, G070H)
